BATHURST

Be the first to review this product

BATHURST

Be the first to review this product

This product is fitment specific

To see if this product is compatible Select a vehicle

Qty

Starting at $347.00

You have not specified your vehicle; therefore, we cannot guarantee this product will fit. Please confirm our limited liability for choosing your own wheel options. To guarantee fitment, please select your vehicle.

Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, TSW Wheels issues this limited warranty to define the rights of the purchaser, and limit TSW Wheels liability, with regard to warranty claims.

TSW Wheels warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the TSW Wheels Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.

See full Warranty details.

Fitment Guide Get in touch with our dedicated support staff

FLOW FORMED TECHNOLOGY

The TSW Bathurst wheel is manufactured using a highly advanced production technique called Flow Formed Technology (FFT). The rim of the wheels is forged at high pressure while the wheel is spun at high speed. This alters the molecular structure and enhances the strength of the alloy. The benefit is a much lighter weight than a regular cast wheel. Most importantly, the weight saving is in the outer rim of the wheel which dramatically reduces rotational mass and enhances vehicle performance.

Specifications Chart

19"

20"

21"

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Cap	MSRP USD
1980BAT405108G72	BATHURST	GLOSS GUNMETAL	19X8	5X108	6.07	40mm	72.10	19.09 lbs	1650	CCPCG18-TMG	$347.00
1980BAT355114G76	BATHURST	GLOSS GUNMETAL	19X8	5X114.3	5.88	35mm	76.10	19.31 lbs	1650	CCPCG18-TMG	$347.00
1985BAT435112G72	BATHURST	GLOSS GUNMETAL	19X8.5	5X112	6.44	43mm	72.10	20.59 lbs	1650	CCPCF82-TMG	$347.00
1985BAT325112G72	BATHURST	GLOSS GUNMETAL	19X8.5	5X112	6.01	32mm	72.10	21.47 lbs	1650	CCPCF82-TMG	$347.00
1985BAT155114G76	BATHURST	GLOSS GUNMETAL	19X8.5	5X114.3	5.34	15mm	76.10	23.02 lbs	1650	CCPCG18-TMG	$347.00
1985BAT355120G76	BATHURST	GLOSS GUNMETAL	19X8.5	5X120	6.13	35mm	76.10	21.25 lbs	1650	CCPCC43-TMG	$347.00
1990BAT305114G76	BATHURST	GLOSS GUNMETAL	19X9	5X114.3	6.18	30mm	76.10	21.10 lbs	1650	CCPCG18-TMG	$435.00
1990BAT155120G76	BATHURST	GLOSS GUNMETAL	19X9	5X120	5.59	15mm	76.10	21.76 lbs	1650	CCPCC43-TMG	$435.00
1995BAT395112G72	BATHURST	GLOSS GUNMETAL	19X9.5	5X112	6.79	39mm	72.10	19.36 lbs	1650	CCPCG18-TMG	$347.00
1995BAT395114G76	BATHURST	GLOSS GUNMETAL	19X9.5	5X114.3	6.79	39mm	76.10	19.36 lbs	1650	CCPCG18-TMG	$435.00
1995BAT395120G76	BATHURST	GLOSS GUNMETAL	19X9.5	5X120	6.79	39mm	76.10	19.36 lbs	1650	CCPCC43-TMG	$347.00
1980BAT405108S72	BATHURST	SILVER W/ MIRROR CUT FACE	19X8	5X108	6.07	40mm	72.10	19.09 lbs	1650	CCPCG18F	$347.00
1980BAT355114S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X8	5X114.3	5.88	35mm	76.10	19.31 lbs	1650	CCPCG18F	$347.00
1985BAT435112S72	BATHURST	SILVER W/ MIRROR CUT FACE	19X8.5	5X112	6.44	43mm	72.10	20.59 lbs	1650	CCPCF82C	$356.00
1985BAT325112S72	BATHURST	SILVER W/ MIRROR CUT FACE	19X8.5	5X112	6.01	32mm	72.10	21.47 lbs	1650	CCPCF82C	$356.00
1985BAT155114S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X8.5	5X114.3	5.34	15mm	76.10	23.02 lbs	1650	CCPCG18F	$356.00
1985BAT355120S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X8.5	5X120	6.13	35mm	76.10	21.25 lbs	1650	CCPCC431C	$356.00
1990BAT305114S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X9	5X114.3	6.18	30mm	76.10	21.10 lbs	1650	CCPCG18F	$435.00
1990BAT155120S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X9	5X120	5.59	15mm	76.10	21.76 lbs	1650	CCPCC431C	$435.00
1995BAT395112S72	BATHURST	SILVER W/ MIRROR CUT FACE	19X9.5	5X112	6.79	39mm	72.10	19.36 lbs	1650	CCPCF82C	$368.00
1995BAT395114S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X9.5	5X114.3	6.79	39mm	76.10	19.36 lbs	1650	CCPCG18F	$368.00
1995BAT395120S76	BATHURST	SILVER W/ MIRROR CUT FACE	19X9.5	5X120	6.79	39mm	76.10	19.36 lbs	1650	CCPCC431C	$435.00

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Cap	MSRP USD
2085BAT405108G72	BATHURST	GLOSS GUNMETAL	20X8.5	5X108	6.32	40mm	72.10	20.77 lbs	1650	CCPCG18-TMG	$391.00
2085BAT205112G72	BATHURST	GLOSS GUNMETAL	20X8.5	5X112	5.54	20mm	72.10	21.34 lbs	1650	CCPCG18-TMG	$391.00
2085BAT405114G76	BATHURST	GLOSS GUNMETAL	20X8.5	5X114.3	6.32	40mm	76.10	20.77 lbs	1650	CCPCG18-TMG	$391.00
2090BAT355112G72	BATHURST	GLOSS GUNMETAL	20X9	5X112	6.38	35mm	72.10	22.42 lbs	1650	CCPCF82-TMG	$391.00
2090BAT205114G76	BATHURST	GLOSS GUNMETAL	20X9	5X114.3	5.79	20mm	76.10	22.44 lbs	1650	CCPCG18-TMG	$391.00
2090BAT305114G76	BATHURST	GLOSS GUNMETAL	20X9	5X114.3	6.18	30mm	76.10	21.85 lbs	1650	CCPCG18-TMG	$391.00
2090BAT355120G76	BATHURST	GLOSS GUNMETAL	20X9	5X120	6.38	35mm	76.10	22.42 lbs	1650	CCPCC43-TMG	$391.00
2090BAT155120G76	BATHURST	GLOSS GUNMETAL	20X9	5X120	5.59	15mm	76.10	22.49 lbs	1650	CCPCC43-TMG	$391.00
2095BAT355114G76	BATHURST	GLOSS GUNMETAL	20X9.5	5X114.3	6.63	35mm	76.10	23.61 lbs	1650	CCPCG18-TMG	$391.00
2010BAT255112G72	BATHURST	GLOSS GUNMETAL	20X10	5X112	6.48	25mm	72.10	22.22 lbs	1650	CCPCG18-TMG	$405.00
2010BAT405112G72	BATHURST	GLOSS GUNMETAL	20X10	5X112	7.07	40mm	72.10	21.56 lbs	1650	CCPCG18-TMG	$405.00
2010BAT405114G76	BATHURST	GLOSS GUNMETAL	20X10	5X114.3	7.07	40mm	76.10	21.56 lbs	1650	CCPCG18-TMG	$405.00
2010BAT355120G76	BATHURST	GLOSS GUNMETAL	20X10	5X120	6.88	35mm	76.10	21.78 lbs	1650	CCPCC43-TMG	$405.00
2005BAT255114G76	BATHURST	GLOSS GUNMETAL	20X10.5	5X114.3	6.73	25mm	76.10	23.55 lbs	1650	CCPCG18-TMG	$489.00
2005BAT255120G76	BATHURST	GLOSS GUNMETAL	20X10.5	5X120	6.73	25mm	76.10	23.55 lbs	1650	CCPCC43-TMG	$413.00
2085BAT205112S72	BATHURST	SILVER W/ MIRROR CUT FACE	20X8.5	5X112	5.54	20mm	72.10	21.34 lbs	1650	CCPCF82C	$399.00
2085BAT405114S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X8.5	5X114.3	6.32	40mm	76.10	20.77 lbs	1650	CCPCG18F	$399.00
2090BAT355112S72	BATHURST	SILVER W/ MIRROR CUT FACE	20X9	5X112	6.38	35mm	72.10	22.42 lbs	1650	CCPCF82C	$410.00
2090BAT305114S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X9	5X114.3	6.18	30mm	76.10	21.85 lbs	1650	CCPCG18F	$410.00
2090BAT205114S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X9	5X114.3	5.79	20mm	76.10	22.44 lbs	1650	CCPCG18F	$410.00
2090BAT155120S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X9	5X120	5.59	15mm	76.10	22.49 lbs	1650	CCPCC431C	$410.00
2090BAT355120S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X9	5X120	6.38	35mm	76.10	22.42 lbs	1650	CCPCC431C	$410.00
2010BAT255112S72	BATHURST	SILVER W/ MIRROR CUT FACE	20X10	5X112	6.48	25mm	72.10	22.22 lbs	1650	CCPCF82C	$428.00
2010BAT405112S72	BATHURST	SILVER W/ MIRROR CUT FACE	20X10	5X112	7.07	40mm	72.10	21.56 lbs	1650	CCPCF82C	$428.00
2010BAT405114S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X10	5X114.3	7.07	40mm	76.10	21.56 lbs	1650	CCPCG18F	$489.00
2010BAT355120S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X10	5X120	6.88	35mm	76.10	21.78 lbs	1650	CCPCC431C	$428.00
2005BAT255114S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X10.5	5X114.3	6.73	25mm	76.10	23.55 lbs	1650	CCPCG18F	$436.00
2005BAT255120S76	BATHURST	SILVER W/ MIRROR CUT FACE	20X10.5	5X120	6.73	25mm	76.10	23.55 lbs	1650	CCPCC431C	$436.00

Part#	Model	Finish	Size	Bolt Pattern	Backspace	Offset	Bore	Weight	Load	Cap	MSRP USD
2190BAT405108G63	BATHURST	GLOSS GUNMETAL	21X9	5X108	6.57	40mm	63.36	27.20 lbs	1980	CCPCG18-TMG	$553.00
2105BAT325112G66	BATHURST	GLOSS GUNMETAL	21X10.5	5X112	7.01	32mm	66.56	28.57 lbs	1980	CCPCG18-TMG	$442.00
2105BAT415112G66	BATHURST	GLOSS GUNMETAL	21X10.5	5X112	7.36	41mm	66.56	28.17 lbs	1980	CCPCG18-TMG	$553.00
