Starting at $347.00
Product Details
Select all options to view Specs
Locate Your Nearest Installer Covered By Wheel Pros Limited Warranty

To the fullest extent recognized by the laws of the state where the wheel was purchased, TSW Wheels issues this limited warranty to define the rights of the purchaser, and limit TSW Wheels liability, with regard to warranty claims.

TSW Wheels warrants that our wheels will be free from structural failure under normal and intended use for as long as the original retail purchaser owns the product. Customers are specifically directed to the TSW Wheels Consumer Information and WTC Aftermarket Wheel Installation Guidelines, supplied with the wheel. Failure to comply with these instructions shall void this warranty.


See full Warranty details.

FLOW FORMED TECHNOLOGY

The TSW Bathurst wheel is manufactured using a highly advanced production technique called Flow Formed Technology (FFT). The rim of the wheels is forged at high pressure while the wheel is spun at high speed. This alters the molecular structure and enhances the strength of the alloy. The benefit is a much lighter weight than a regular cast wheel. Most importantly, the weight saving is in the outer rim of the wheel which dramatically reduces rotational mass and enhances vehicle performance.

Specifications Chart

19"
20"
21"
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
1980BAT405108G72 BATHURST GLOSS GUNMETAL 19X8 5X108 6.07 40mm 72.10 19.09 lbs 1650 0.00 CCPCG18-TMG $347.00
1980BAT355114G76 BATHURST GLOSS GUNMETAL 19X8 5X114.3 5.88 35mm 76.10 19.31 lbs 1650 0.00 CCPCG18-TMG $347.00
1985BAT435112G72 BATHURST GLOSS GUNMETAL 19X8.5 5X112 6.44 43mm 72.10 20.59 lbs 1650 0.00 CCPCF82-TMG $347.00
1985BAT325112G72 BATHURST GLOSS GUNMETAL 19X8.5 5X112 6.01 32mm 72.10 21.47 lbs 1650 0.00 CCPCF82-TMG $347.00
1985BAT155114G76 BATHURST GLOSS GUNMETAL 19X8.5 5X114.3 5.34 15mm 76.10 23.02 lbs 1650 0.00 CCPCG18-TMG $347.00
1985BAT355120G76 BATHURST GLOSS GUNMETAL 19X8.5 5X120 6.13 35mm 76.10 21.25 lbs 1650 0.00 CCPCC43-TMG $347.00
1990BAT305114G76 BATHURST GLOSS GUNMETAL 19X9 5X114.3 6.18 30mm 76.10 21.10 lbs 1650 0.00 CCPCG18-TMG $435.00
1990BAT155120G76 BATHURST GLOSS GUNMETAL 19X9 5X120 5.59 15mm 76.10 21.76 lbs 1650 0.00 CCPCC43-TMG $435.00
1995BAT395112G72 BATHURST GLOSS GUNMETAL 19X9.5 5X112 6.79 39mm 72.10 19.36 lbs 1650 0.00 CCPCG18-TMG $347.00
1995BAT395114G76 BATHURST GLOSS GUNMETAL 19X9.5 5X114.3 6.79 39mm 76.10 19.36 lbs 1650 0.00 CCPCG18-TMG $435.00
1995BAT395120G76 BATHURST GLOSS GUNMETAL 19X9.5 5X120 6.79 39mm 76.10 19.36 lbs 1650 0.00 CCPCC43-TMG $347.00
1980BAT405108S72 BATHURST SILVER W/ MIRROR CUT FACE 19X8 5X108 6.07 40mm 72.10 19.09 lbs 1650 0.00 CCPCG18F $347.00
1980BAT355114S76 BATHURST SILVER W/ MIRROR CUT FACE 19X8 5X114.3 5.88 35mm 76.10 19.31 lbs 1650 0.00 CCPCG18F $347.00
1985BAT435112S72 BATHURST SILVER W/ MIRROR CUT FACE 19X8.5 5X112 6.44 43mm 72.10 20.59 lbs 1650 0.00 CCPCF82C $356.00
1985BAT325112S72 BATHURST SILVER W/ MIRROR CUT FACE 19X8.5 5X112 6.01 32mm 72.10 21.47 lbs 1650 0.00 CCPCF82C $356.00
1985BAT155114S76 BATHURST SILVER W/ MIRROR CUT FACE 19X8.5 5X114.3 5.34 15mm 76.10 23.02 lbs 1650 0.00 CCPCG18F $356.00
1985BAT355120S76 BATHURST SILVER W/ MIRROR CUT FACE 19X8.5 5X120 6.13 35mm 76.10 21.25 lbs 1650 0.00 CCPCC431C $356.00
1990BAT305114S76 BATHURST SILVER W/ MIRROR CUT FACE 19X9 5X114.3 6.18 30mm 76.10 21.10 lbs 1650 0.00 CCPCG18F $435.00
1990BAT155120S76 BATHURST SILVER W/ MIRROR CUT FACE 19X9 5X120 5.59 15mm 76.10 21.76 lbs 1650 0.00 CCPCC431C $435.00
1995BAT395112S72 BATHURST SILVER W/ MIRROR CUT FACE 19X9.5 5X112 6.79 39mm 72.10 19.36 lbs 1650 0.00 CCPCF82C $368.00
1995BAT395114S76 BATHURST SILVER W/ MIRROR CUT FACE 19X9.5 5X114.3 6.79 39mm 76.10 19.36 lbs 1650 0.00 CCPCG18F $368.00
1995BAT395120S76 BATHURST SILVER W/ MIRROR CUT FACE 19X9.5 5X120 6.79 39mm 76.10 19.36 lbs 1650 0.00 CCPCC431C $435.00
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
2085BAT405108G72 BATHURST GLOSS GUNMETAL 20X8.5 5X108 6.32 40mm 72.10 20.77 lbs 1650 0.00 CCPCG18-TMG $391.00
2085BAT205112G72 BATHURST GLOSS GUNMETAL 20X8.5 5X112 5.54 20mm 72.10 21.34 lbs 1650 0.00 CCPCG18-TMG $391.00
2085BAT405114G76 BATHURST GLOSS GUNMETAL 20X8.5 5X114.3 6.32 40mm 76.10 20.77 lbs 1650 0.00 CCPCG18-TMG $391.00
2090BAT355112G72 BATHURST GLOSS GUNMETAL 20X9 5X112 6.38 35mm 72.10 22.42 lbs 1650 0.00 CCPCF82-TMG $391.00
2090BAT205114G76 BATHURST GLOSS GUNMETAL 20X9 5X114.3 5.79 20mm 76.10 22.44 lbs 1650 0.00 CCPCG18-TMG $391.00
2090BAT305114G76 BATHURST GLOSS GUNMETAL 20X9 5X114.3 6.18 30mm 76.10 21.85 lbs 1650 0.00 CCPCG18-TMG $391.00
2090BAT355120G76 BATHURST GLOSS GUNMETAL 20X9 5X120 6.38 35mm 76.10 22.42 lbs 1650 0.00 CCPCC43-TMG $391.00
2090BAT155120G76 BATHURST GLOSS GUNMETAL 20X9 5X120 5.59 15mm 76.10 22.49 lbs 1650 0.00 CCPCC43-TMG $391.00
2095BAT355114G76 BATHURST GLOSS GUNMETAL 20X9.5 5X114.3 6.63 35mm 76.10 23.61 lbs 1650 0.00 CCPCG18-TMG $391.00
2010BAT255112G72 BATHURST GLOSS GUNMETAL 20X10 5X112 6.48 25mm 72.10 22.22 lbs 1650 0.00 CCPCG18-TMG $405.00
2010BAT405112G72 BATHURST GLOSS GUNMETAL 20X10 5X112 7.07 40mm 72.10 21.56 lbs 1650 0.00 CCPCG18-TMG $405.00
2010BAT405114G76 BATHURST GLOSS GUNMETAL 20X10 5X114.3 7.07 40mm 76.10 21.56 lbs 1650 0.00 CCPCG18-TMG $405.00
2010BAT355120G76 BATHURST GLOSS GUNMETAL 20X10 5X120 6.88 35mm 76.10 21.78 lbs 1650 0.00 CCPCC43-TMG $405.00
2005BAT255114G76 BATHURST GLOSS GUNMETAL 20X10.5 5X114.3 6.73 25mm 76.10 23.55 lbs 1650 0.00 CCPCG18-TMG $489.00
2005BAT255120G76 BATHURST GLOSS GUNMETAL 20X10.5 5X120 6.73 25mm 76.10 23.55 lbs 1650 0.00 CCPCC43-TMG $413.00
2085BAT205112S72 BATHURST SILVER W/ MIRROR CUT FACE 20X8.5 5X112 5.54 20mm 72.10 21.34 lbs 1650 0.00 CCPCF82C $399.00
2085BAT405114S76 BATHURST SILVER W/ MIRROR CUT FACE 20X8.5 5X114.3 6.32 40mm 76.10 20.77 lbs 1650 0.00 CCPCG18F $399.00
2090BAT355112S72 BATHURST SILVER W/ MIRROR CUT FACE 20X9 5X112 6.38 35mm 72.10 22.42 lbs 1650 0.00 CCPCF82C $410.00
2090BAT305114S76 BATHURST SILVER W/ MIRROR CUT FACE 20X9 5X114.3 6.18 30mm 76.10 21.85 lbs 1650 0.00 CCPCG18F $410.00
2090BAT205114S76 BATHURST SILVER W/ MIRROR CUT FACE 20X9 5X114.3 5.79 20mm 76.10 22.44 lbs 1650 0.00 CCPCG18F $410.00
2090BAT155120S76 BATHURST SILVER W/ MIRROR CUT FACE 20X9 5X120 5.59 15mm 76.10 22.49 lbs 1650 0.00 CCPCC431C $410.00
2090BAT355120S76 BATHURST SILVER W/ MIRROR CUT FACE 20X9 5X120 6.38 35mm 76.10 22.42 lbs 1650 0.00 CCPCC431C $410.00
2010BAT255112S72 BATHURST SILVER W/ MIRROR CUT FACE 20X10 5X112 6.48 25mm 72.10 22.22 lbs 1650 0.00 CCPCF82C $428.00
2010BAT405112S72 BATHURST SILVER W/ MIRROR CUT FACE 20X10 5X112 7.07 40mm 72.10 21.56 lbs 1650 0.00 CCPCF82C $428.00
2010BAT405114S76 BATHURST SILVER W/ MIRROR CUT FACE 20X10 5X114.3 7.07 40mm 76.10 21.56 lbs 1650 0.00 CCPCG18F $489.00
2010BAT355120S76 BATHURST SILVER W/ MIRROR CUT FACE 20X10 5X120 6.88 35mm 76.10 21.78 lbs 1650 0.00 CCPCC431C $428.00
2005BAT255114S76 BATHURST SILVER W/ MIRROR CUT FACE 20X10.5 5X114.3 6.73 25mm 76.10 23.55 lbs 1650 0.00 CCPCG18F $436.00
2005BAT255120S76 BATHURST SILVER W/ MIRROR CUT FACE 20X10.5 5X120 6.73 25mm 76.10 23.55 lbs 1650 0.00 CCPCC431C $436.00
Part# Model Finish Size Bolt Pattern Backspace Offset Bore Weight Load Lip Size Cap MSRP USD
2190BAT405108G63 BATHURST GLOSS GUNMETAL 21X9 5X108 6.57 40mm 63.36 27.20 lbs 1980 0.00 CCPCG18-TMG $553.00
2105BAT325112G66 BATHURST GLOSS GUNMETAL 21X10.5 5X112 7.01 32mm 66.56 28.57 lbs 1980 0.00 CCPCG18-TMG $442.00
2105BAT415112G66 BATHURST GLOSS GUNMETAL 21X10.5 5X112 7.36 41mm 66.56 28.17 lbs 1980 0.00 CCPCG18-TMG $553.00
